ZS-HS1500PB *AS Model*
ZS-HS1500PB is a 2-way speaker system with digital amplifier made of resin, and features a large diameter woofer. It can be installed and used in many diffrent application with combined use of the supplied accessories and/or the optional mounting brackets.
| Enclosure | Sealed type |
|---|---|
| Power Source | 220 - 240 V AV, 50/60 Hz |
| Rated Output | 170 W |
| Power Consumption | 100 W |
| Sensitivity | 98 dB (1 W, 1 m) |
| Frequency Response | 60 - 20 kHz |
| Input | MIC/LINE: XLR-3-31 type combination connector (balanced/unbalanced, -60dB/dB selective) AUX: XLR-3-31 type connector, -10dB unbalanced |
| Output | LINE out: XLR-3-31 type connector, 0dB unbalanced |
| Tone Control | Bass: ±10dB at 100Hz Treble: ±10dB at 10kHz |
| Operating Temperature | -10℃ to +40℃ |
| Finish | Enclosure: Polypropylene, black Punched Net: Surface-treated steel plate, black |
| Dimensions | 451 (W) × 560 (H) × 400 (D) mm (17.76" × 22.05" × 15.75") |
| Weight | 16 kg (35.2 lb) unit only |
| Accessory | Power Cord (2m) x 1 |
| Option | Mounting bracket: HY-1500VB, HY-1500HB Ceiling mount bracket: HY-C0801 Wall mount bracket: HY-W0801 Speaker stand: ST-34B |
