ZS-PJ64 Projection Speaker

ZS-PJ64 Projection Speaker

ZS-PJ64 Projection Speaker

ZS-PJ64

The ZS-PJ64 is a projection speaker designed for ceiling and wall installations. Considered in architectural design, it can blend in with lighting equipment. The supplied swivel bracket allows for flexible speaker angle adjustment. The ZS-PJ64 is driven on high-impedance (100 V and 70 V) line. The input power (impedance) can be easily changed at the upper side of the speaker. The speaker is easy to repaint so as to meet a wide range of design needs.

Rated Input 6 W (100 V line)
Rated Impedance 100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 10 kΩ (1 W)
70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
Sound Pressure Level  90 dB (1 W, 1 m)
Frequency Response 100 - 18,000 Hz
Finish Enclosure: HIPS resin, off-white
Grille: Surface-treated steel plate net, off-white, paint
Dimensions φ186 × 369 (H) mm
Weight 1.5 kg
